Appendix C
Pipeline Control Codec Profiles
154
March, 2009
DVCPRO HD PROFILES
Table C–4. DVCPro HD Codec
IMX PROFILES
Table C–5. IMX Codec
Parameter Value
Resolution 720p (1280 x 720) | 1080i (1920 x 880)
Frame Rate 23.98 | 25 | 29.97 | 50 | 59.94 fps
Quality (mbit/sec) 100 mb/sec
Scanning Interlaced | Progressive
Field Order (Int.) 1080i: Upper Field First
Frame Aspect Ratio 16:9
Pixel Aspect Ratio NTSC/PAL CCIR 601
Audio Uncompressed PCM, 16 Bit Integer, Big Endian
Parameter Value
Resolution 486i (720 x 486 NTSC) | 576i (720 x 576 PAL)
Frame Rate 29.97 fps (NTSC), 25 fps (PAL)
Quality (mbit/sec) 30 | 30 Anamorphic | 40 | 40 Anamorphic | 50 | 50
Anamorphic
Scanning Interlaced
Field Order (Int.) Lower Field First (NTSC), Upper Field First (PAL)
Frame Aspect Ratio 4:3
Pixel Aspect Ratio NTSC/PAL CCIR 601
Audio Uncompressed PCM, 16 Bit Integer, Big Endian
