Pipeline SC - Linear PCM Audio Profile; Motion JPEG Profiles; Uncompressed Profiles

Appendix C
Pipeline Control Codec Profiles
156
March, 2009
MOTION JPEG PROFILES
Motion JPEG A is supported in SD profiles; Standard and HQ are supported in HD profiles.
Table C–7. Motion JPEG Codec
UNCOMPRESSED PROFILES
Table C–8. Uncompressed Codec
LINEAR PCM AUDIO PROFILE
Table C–9. Linear PCM Codec
Parameter Value
Resolution 240p (720 x 480 NTSC)
Frame Rate 25 | 29.97 fps
Quality (mbit/sec) Q80
Parameter Value
Resolution 480i (720 x 480 NTSC) | 486i (720 x 486 NTSC) |
576i (720 x 576 PAL)
Frame Rate 29.97 fps
Quality (bits) 8 | 8 Anamorphic | 10 | 10 Anamorphic
Scanning Interlaced
Field Order (Int.) Lower Field First (NTSC), Upper Field First (PAL)
Frame Aspect Ratio 4:3
Pixel Aspect Ratio NTSC/PAL CCIR 601
Parameter Value
Channels 2 | 4 | 8
Sample Rate 48 kHZ
Quality 16 | 24 bit, Big Endian | Little Endian
