User’s Manual of WGSW-20160HP/WGSW-24040HP series
31
Product WGSW-24040HP WGSW-24040HP4
Hardware Specifications
Copper Ports 24 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
10/100/1000Mbps / SFP Combo
Interfaces
4 10/100/1000Mbps TP and SFP shared combo interfaces, SFP(Mini-GBIC)
supports 100/1000Mbps Dual mode DDM, shared with Port-21 to Port-24
Console 1 x RS-232 DB9 serial port (115200, 8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 48Gbps / non-blocking
Throughput 35.7Mpps@64Bytes
Address Table 8K entries, automatic source address learning and ageing
Share Data Buffer 4 megabits
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame 9Kbytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
LED
System:
Power (Green)
Alert:
FAN1 (Green), FAN2 (Green), PWR (Green)
PoE Ethernet Interfaces (Port 1 to Port 24):
LNK/ACT (10/100/1000Mbps, Green), PoE In-Use (Orange)
100/1000Mbps SFP Combo Interfaces (Port 21 to Port 24):
1000 (LNK/ACT, Green), 100 (LNK/ACT, Orange)
Power Requirements
100~240V AC, 50/60Hz, 4A 100~240V AC, 50/60Hz, 6A
Power Consumption (Full Load)
262 watts 482 watts
ESD Protection
6KV DC
Power over Ethernet
PoE Standard
IEEE 802.3af / 802.3at PoE / PSE
PoE Power Supply Type
End-Span
PoE Power Output
56V DC per port
Max. 30.8 watts
Power Pin Assignment
1/2(+), 3/6(-)
PoE Power Budget Max. 220 watts Max. 440 watts
PoE Ability
PD @ 7 Watts
24 units 24 units
PD @ 15.4 Watts
24 units 24 units
PD @ 30.8 Watts
7 units
14 units
Layer 2 Management Function
Basic Management Interfaces Console, Telnet, Web Browser, SNMP v1, v2c
