Chapter F: PARTS REPLACEMENT AND REPAIR 4 C-ARM AND UPPER ARM PARTS REPLACEMENT
Technical manual Planmeca ProOne 175
4. Route the cables through the linear rotation block so that the marks are in the opening
level. i
5. Add two cable ties to the cable guide as shown on the figure below.
6. Route the cables through the cable guide.
