9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
4.3
3. Remove the screws
w
that attach the ECU to the
driver’s rear fender well.
4. With the ignition turned off, disconnect the wire
harness from the ECU. Lift the connector locking
lever and rotate it up until the connector is free from
the ECU.
NOTICE
Upon removing the ECU connector, you should hear a
“click” when the connector is fully open.
5. To install, reverse the procedure and tighten the
mounting screws to specification.
NOTICE
Upon installing the ECU connector, you should hear a
“click” when the connector is fully closed.
TORQUE
ECU Retaining Screws:
24 lb-in (2.7 Nm)
ENGINE ELECTRICAL
