5
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
5.3
SPECIAL TOOLS - FUEL SYSTEM
TOOL DESCRIPTION PART NUMBER
Fuel Pressure Gauge Kit
PU-43506-A
Fuel Pressure Gauge
Adapter
PA-48838
Fuel Pump Service Tool
PU-50326
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com/
WARNING
The EFI fuel system remains under high pressure, even
when the engine is not running. Before attempting to
service any part of the fuel system, pressure should be
relieved. The Fuel Pressure Gauge Kit has an
integrated pressure relief valve that can be used to
bleed off pressure once you have completed the fuel
pressure test.
SERVICE SPECIFICATIONS - FUEL
SYSTEM
PART DESCRIPTION
SERVICE
SPECIFICATION
Fuel Pump Output 9.25 gal (35 L)/hr
Fuel Pressure
58 ± 2 psi (400 ± 14 kPa)
Fuel Sender Resistance -
Empty
450 ± 5 Ω
Fuel Sender Resistance -
Full
100 ± 3 Ω
Fuel Injector Resistance
11.4 - 12.6 Ω
FUEL SYSTEM
