ASSEMBLY VIEWS - BODY / FRAME
FRONT FACIA ASSEMBLY VIEW
q
Lower Front Fascia
y
Front Radiator Shroud
w
Front Fascia Fasteners
3.5 lb-ft (4.7 Nm)
u
Radiator Shroud Fasteners
22 in-lbs (2.5 Nm)
e
Upper Front Fascia
i
LH Lower Front Fascia Bracket
r
Lower Front Fascia Bracket Fasteners
3.5 lb-ft (4.7 Nm)
o
Bumper Screen
t
RH Lower Front Fascia Bracket
a
Plastic Push Rivet
