11
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
11.51
SEAT REMOVAL
1. To remove any of the seats, lift upward on the latch
lever located behind the seat bottom.
2. Lift upward and forward on the seat while lifting up on
the latch lever to remove the seat from the vehicle.
HOOD REMOVAL
1. Rotate the latches 90° to release the hood from the
vehicle.
2. Pull the hood forward and up to remove from the
vehicle.
EXTERIOR BODY COMPONENT
REMOVAL
1. Remove the hood from the vehicle. Refer to “Hood
Removal” page 11.51 procedure.
2. Remove the front bumper from the vehicle. Refer to
“Front Bumper Removal” page 13.19 procedure.
FRONT FENDER FLAIR REMOVAL
1. Remove the fastener holding the front fender flair to
the front fender. Pull the front fender flair from the
tabs holding it to the vehicle.
FRONT FENDER REMOVAL
1. Remove the fasteners holding the front fender to the
vehicle. Pull the front fender off the vehicle.
NOTICE
Remove the front grill mesh to access the fasteners on
the front of the fender.
BODY / FRAME
