7
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
7.3
SHIFT CABLE SERVICE
SHIFT LEVER / CABLE ASSEMBLY VIEW - GENERAL
q
Shift Lever
t
Shift Cable Nut
13 lb-ft (18 Nm)
w
Shifter Boot
y
Rear Shifter Cable Jam Nut
13 lb-ft (18 Nm)
e
Front Shifter Cable Jam Nut
18 lb-ft (24 Nm)
u
Bushing
r
Shift Cable i
Retaining Clip
TRANSMISSION
