13.62
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
AMBIENT AIR TEMPERATURE SENSOR
SERVICE
REMOVAL
1. Depress two tabs on top of grille, then tip forward.
2. Disconnect the main chassis connector from front
camera connector and remove the grille
3. In right front wheel well, disconnect ambient air
temperature sensor connector
q
from connector
w
on main chassis harness.
NOTICE
Front fascia hidden for clarity.
Chassis structure may vary slightly from that shown.
4. Carefully cut the ziptie portion of the edge clip
e
securing the ambient air temperature sensor harness.
5. Carefully remove the ambient air temperature sensor
harness by pulling harness up along the regulator
harness and through slot in RH side of radiator
shroud.
INSTALLATION
1. In right front wheel well, join ambient air temperature
sensor connector
q
to connector
w
on main chassis
harness.
NOTICE
Front fascia hidden for clarity.
Chassis structure may vary slightly from that shown.
FACTORY-INSTALLED OPTIONS
