9.20
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
4. While supporting the power steering unit, remove the
fasteners holding the mount bracket to the vehicle.
5. Carefully remove the power steering unit and mount
bracket from the vehicle as an assembly.
6. If replacing the power steering unit, remove the
fasteners that retain the power steering unit to the
mount bracket.
WARNING
Electronic Power Assisted Steering (EPAS) units are
programmed to be vehicle specific and are not
interchangeable between product lines.
STEERING SHAFT REMOVAL - LOWER
1. Use the steering wheel to position the front wheels so
they point straight ahead.
2. Locate the lower steering shaft through the left front
wheel well. Mark the lower steering shaft, gear box
stub shaft and gear box to aid installation.
3. Remove the power steering unit . Refer to “Power
Steering Unit Removal” page 9.19 procedure.
4. Remove the pinch bolt retaining the lower steering
shaft to the steering gear box assembly .
5. Lift up on the shaft and remove it through the floor
panel.
STEERING / SUSPENSION
