13
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
13.67
4. Join connector from antenna to connector on RIDE
COMMAND harness. Ensure harness is routed and
secured to roof panel using two edge clips.
VEHICLE-TO-VEHICLE (V2V) ANTENNA
SERVICE (4-SEAT)
REMOVAL
1. Disconnect the V2V antenna connector from RIDE
COMMAND
®
harness .
2. Cut and remove the panduit strap securing antenna
harness to the ROPS.
3. Open the clamshell cover and remove the two
fasteners securing the V2V antenna to ROPS B-pillar
bracket.
4. Carefully remove the V2V antenna by removing the
antenna cable through hole in ROPS B-pillar bracket.
FACTORY-INSTALLED OPTIONS
