9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
3. Remove the three fasteners securing the HECU to its
bracket.
4. Remove the HECU for the vehicle.
ABS HECU INSTALLATION (INTL ABS)
1. Install the HECU onto its bracket.
2. Install three HECU fasteners
q
and torque to
specification in sequence.
TORQUE
ABS HECU Mounting Fasteners (INTL):
Step 1: Pre torque all three fasteners to 1.8 lb-ft (2
Nm) Step 2: Torque all three fasteners to 3 lb-ft (4
Nm) Step 3: Torque all three fasteners to 4 lb-ft (5.4
Nm)
BRAKE SYSTEM
