FRONT BUMPER INSTALLATION
1. Install the front bumper on the vehicle and align
mounting points. Install the front bumper lower
mounting fasteners and torque to specification.
TORQUE
Front Bumper Fasteners:
30 lb-ft (41 Nm)
2. Install the front bumper upper mounting fasteners and
torque to specification.
TORQUE
Front Bumper Fasteners:
30 lb-ft (41 Nm)
3. Install the upper mounting fastener end caps from the
front bumper.
4. Install the pin attaching the winch hook.
FACTORY-INSTALLED OPTIONS
