9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
13.11
REAR VIEW MIRROR REMOVAL
1. Remove the top mounting fastener from the rear view
mirror.
2. Remove the rear view mirror from the front support
ROPS, taking care not to lose the mounting bracket.
REAR VIEW MIRROR INSTALLATION
1. Install the foam pads on the inside surface of the
lower and upper mirror arms to help secure mirror to
the tube.
2. Install the rear view mirror onto the front support
ROPS and align with audio system mounting slot.
3. Install mounting fastener and torque to specification.
TORQUE
Rear View Mirror Fastener:
5 lb-ft (7 Nm)
4. Adjust the rear mirror view with respect to the driver’s
seat position.
NOTICE
Tightening or loosening the lower screw will make
adjustment harder or easier depending on torque.
FACTORY-INSTALLED OPTIONS
