9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
10.89
3. Install brake lines in proper orientation. Torque M12
Banjo bolts
w
to specification
TORQUE
ABS HECU M12 Bajo Bolts (INTL):
30 lb-ft (41 Nm)
4. Torque flare fittings
e
to specification.
TORQUE
ABS HECU Flare Fittings (INTL):
15 lb-ft (20 Nm)
5. Connect ABS HECU electrical connector
r
.
6. Bleed Brake System.
ABS TROUBLESHOOTING (INTL ABS)
• Bent Wheel speed sensor bracket
• Damaged tone ring ( broken / missing teeth)
• Incorrect wheel speed sensor air gap
• Tone ring slid off from its original position
• Faulty HECU
• Faulty brake pressure switch
• Wheels Speed Sensor wire short
• Brake line leak
• Undersized or Oversized Tires
• Faulty wheel speed sensor
• Faulty wheel speed sensor wiring
• Low brake fluid
• Air in brake system
BRAKE SYSTEM
