13
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
13.27
AUDIO HARNESS ROUTING
q
Routing Clips
The RH branch of audio harness is secured to the top of
the dash support tube. The white tape on the harness
signifies a routing retention point.
w
Double Cable Tie
The LH branch of audio harness is secured to the main
chassis harness. The white tape on the harness signifies
a cable tie retention point.
NOTICE
If harness replacement is required, note the routing of the harness for installation purposes.
FACTORY-INSTALLED OPTIONS
