9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
6.3
SERVICE SPECIFICATIONS - PVT
SYSTEM
PART
DESCRIPTION
SERVICE
SPECIFICATION
SERVICE
LIMIT
Drive Clutch
Spring Part
Number
7044263
-
Drive Clutch
Spring Color
Black / Red
-
Drive Clutch
Spring Free
Length
3.219 in (8.18
cm)
-
Drive Clutch
Spring Part
Number -
CREW
7044465
-
Drive Clutch
Spring Color -
CREW
Black
-
Drive Clutch
Spring Free
Length - CREW
3.75 in (9.52 cm)
-
Drive Clutch
Button to Tower
Clearance
0.000-0.012 in
(0.000-0.304 mm)
-
Drive Clutch
Shaft Diameter
1.3725-1.3712 in
(34.8615-34.8488
mm)
1.3704 in
(34.8088 mm)
Vespel® Thrust
Washer
Thickness
0.030 in (0.76
mm)
0.025 in (0.64
mm)
PVT SYSTEM
