9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
ROOF REMOVAL - GENERAL 4
1. Remove the roof mounting bracket fasteners.
2. Remove upper rear fasteners from the ROPS visor.
3. Push up and forward on the back of the roof to
remove it from the ROPS visor.
ROOF INSTALLATION - GENERAL 4
1. Ensure the ROPS Visor Trim Panel has been
installed.
2. With the help of an assistant, place the roof onto the
top of the ROPS.
3. Engage the front hooks into the ROPS Trim Panel
and slide the roof rear to lock into place.
4. Install mounting bracket on the rear ROPS and align
mounting points.
5. Install mounting bracket fasteners and torque to
specification.
TORQUE
Roof Mounting Bracket Fasteners:
8 lb-ft (11 Nm)
