10
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
10.87
3. Ensure the sensor is touching the feel gauge and
tighten the fasteners
w
.
NOTICE
With the fasteners tightened the feeler gauge should be
able to be inserted and removal with a minimal amount
of force.
4. With the proper air gap attained, torque the fasteners
to specification.
TORQUE
ABS Sensor Mount (INTL):
5 lb-ft (7 Nm)
5. Repeat the procedure on the adjacent side of the
gearcase.
ABS HECU REMOVAL (INTL ABS)
The ABS HECU can be accessed through the right front
wheel well.
1. Disconnect the ABS HECU electrical connector
q
.
2. Disconnect the brake lines
w
and allow the brake
fluid to drain.
NOTICE
Note orientation and location of each brake line for
reassembly.
BRAKE SYSTEM
To Next Page
