8
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
8.57
13.Without removing the front propshaft from the support
bearing, slide the assembly rearward to disengage
the front propshaft from the gearcase input shaft.
14.Disconnect the wire harness for the front gearcase
and remove the harness from the retaining dart.
15.Remove the vent line from the front gearcase and
plug vent line fitting.
16.Remove the four fasteners
r
securing the front
gearcase to the frame.
17.Rotate front of gearcase up so the input shaft is
facing down. Lift and remove the gearcase from the
front LH wheel well area and slide it out of the vehicle
above the upper A-arm.
FINAL DRIVE
