REAR VIEW
q
LH Rear Upper Control Arm
o
Pivot Cap Asm.
w
Shock Mounting Fasteners
a
Washer
e
Washer
s
Nut
81 lb-ft (110 Nm)
r
Nut
51 lb-ft (70 Nm)
d
Rear Inner Control Arm Fastener
t
RH Rear Upper Control Arm
f
LH Rear Lower Control Arm
y
RH Rear Lower Control Arm
g
Nut
81 lb-ft (110 Nm)
u
Pivot Shaft Short
h
Washer
i
Bushing
j
Rear Bearing Carrier Fastener
