9.64
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
20.Use torque cap socket or adjustable wrench to
remove body cap.
CAUTION
Body Cap will be hot.
21.Discard all O-rings and clean Loctite® residue
completely out of threads of the body.
22.Clean body cap using a wire brush and pick.
23.Remove both retaining rings in the body cap using a
sharp pick.
24.Press the bearing out of the body cap using a bearing
press set or assorted sockets.
25.Prep the threads on the body cap with Loctite®
primer 7649 and set aside.
26.Place shock shaft assembly in clamp blocks and
remove nut from non-BOC equipped shaft assembly.
27.For Bottom Out Cup equipped shocks, remove the
retaining ring from the Bottom Out Post.
STEERING / SUSPENSION
