9.66
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
33.Note the orientation of the notches in the bleed shim
align with the compression ports of the piston.
34.Remove the piston bearing if it shows any signs of
damage or wear.
35.Remove piston O-ring.
36.Remove compression valve stack .
37.Remove bearing assembly and bearing cap.
38.Place shock shaft in clamp blocks.
STEERING / SUSPENSION
