9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
11.61
FRONT CLOSEOFF PANEL REMOVAL
1. Remove the fasteners holding the front close-of panel
to the vehicle.
REAR FLOOR REMOVAL
1. Remove the fasteners holding the front seat base
frame to the vehicle.
2. Remove the remaining fasteners holding the rear RH
and LH floors to the vehicle.
MAIN FLOOR REMOVAL
1. Remove the brake pedal, accelerator pedal, and
mounting bracket. Refer to “Brake Pedal Removal”
page 10.48 procedure.
2. Remove the remaining fasteners holding the RH and
LH main floors to the vehicle.
BODY / FRAME
