9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
12.17
REAR VIEW
w
Relay/Fuse Block
s
ETC Throttle Body
2!
Stator AC
w
Start Solenoid d
Turf Relay
2@
Fuel Pump & Sender
e
Start Solenoid B+ 1
f
Taillight Harness
2#
12V Receptacle LO (Console)
r
Start Solenoid B+ 2
g
Trailer Jumper
2$
12V Receptacle HI (Console)
t
ECM, Code 4
h
Vehicle Speed Sensor
2%
Park Brake
y
ECM, Code 13
j
Transmission Switch
2^
Seatbelt Switch
u
Ignition Coil
k
Crank Position Sensor
2&
Ground, Rear Chassis #4
i
Ground, Ignition Coil
l
MAG Fuel Injector
2*
Ground, Rear Chassis #3
o
Coolant Temp Sensor
1(
T-Map
2(
Ground, Rear Chassis #2
a
Oxygen Sensor
2)
PTO Fuel Injector
3)
Ground, Rear Chassis #1
CHASSIS / BODY ELECTRICAL
