13.30
9850067 R01 - 2020-2021 GENERAL / GENERAL XP Service Manual
© Copyright Polaris Inc.
4. Carefully pull the speaker out of the speaker housing.
IMPORTANT
Do not allow the speaker to hang from the harness.
5. Disconnect the speaker connectors
e
and remove
the speaker.
INSTALLATION
1. Connect the speaker connectors
e
and carefully
install the speaker back into the speaker housing.
2. Install the four speaker fasteners
w
. Torque fasteners
to specification.
TORQUE
Speaker Fasteners:
11 in-lbs (1.25 Nm)
3. Install the speaker cover and align mounting holes.
FACTORY-INSTALLED OPTIONS
