Repair Tools and Other Materials
OUO1004,0000BC3 –19–01NOV00–6/16
RG6246 –UN–05DEC97
D17526CI/D17527CI
Dial Indicator .....D17526CI (English, in.) or D17527CI
(Metric, mm)
Use with JDG451 or KJD10123 to measure valve recess
and cylinder liner height-to-cylinder block top deck.
05
170
3
OUO1004,0000BC3 –19–01NOV00–7/16
RG8506 –UN–20MAY98
JDG982
Valve Spring Compressor ................JDG982
Use to compress exhaust and intake valve springs for
removal and installation.
OUO1004,0000BC3 –19–01NOV00–8/16
RG5061 –UN–05DEC97
D01168AA
Spring Compression Tester ............. D01168AA
Test valve spring compression.
OUO1004,0000BC3 –19–01NOV00–9/16
RG5065 –UN–05DEC97
JDG164A
Valve Seat Pilot Driver .................JDG164A
Use with JDG1166 Adapter to install intake and exhaust
valve seat inserts, and with JDG1167 Adapter to install
valve guides.
CTM100 (06APR04)
05-170-3
P
OWER
T
ECH
10.5 L & 12.5 L Diesel Engines
040604
PN=377
Continued on next page
