PREVOST X3-45 Multiplex User Manual

Page No.17
NDS2 issue A
Spicer SpecialityAxle Division - Technical Publications
© Spicer Speciality Axle Division
PART N
O
DESCRIPTION TIGHTENING TORQUE
1 Wheel nut M18 x 1.5 ----------------------------------------------- 235 - 260 lbs.ft 318 - 352NM
Wheel nut M20 x 1.5 ----------------------------------------------- 285 - 315 lbs.ft 386 - 427NM
Wheel nut M22 x 1.5 ----------------------------------------------- 475 - 525 lbs.ft 644 - 712NM
20 Hub flange retaining bolt M14 x 1.5---------------------------- 174 - 192 lbs.ft 236 - 260NM
21 Brake drum retaining screw-------------------------------------- 26 - 32 lbs.ft 35 - 43NM
Fig.No.21
1
2
3
4
5
7
8
9<
6
BACK / RETOUR

PREVOST X3-45 Multiplex Specifications

General

Length	45 ft
Width	102 in
Engine	Volvo D13
Horsepower	500 hp
GVWR	54, 000 lbs
Height	146 in
Sleeping Capacity	Varies based on floor plan
Water Capacity	Varies based on floor plan
