Appendix D: Specifications
Murata Bluetooth Radio
Psion EP10 Hand-Held Computer User Manual
D-6
D.2.2 Murata Bluetooth Radio
Transmit Power 802.11b +18 dBm typical
802.11g +13 dBm typical
802.11a +12 dBm typical
802.11n (2.4 GHz) +12 dBm typical
802.11n (5 GHz) +12 dBm typical
Frequency Range 802.11b/g/n 2400-2484 MHz
802.11a/n 5150-5350 MHz, 5480-5720 MHz and 5725-
5845 MHz
RX Sensitivity 802.11b -78 dBm @ 11 Mbps
802.11g -67 dBm @ 54 Mbps
802.11a -67 dBm @ 54 Mbps
802.11n (2.4 GHz) -66 dBm @ 65 Mbps
802.11n (5 GHz -66 dBm @ 65 Mbps
Data Rates 802.11b 1,2,5.5,11 Mbps
802.11a/g 6,9,12,18,24,36,48,54 Mbps
802.11n 6.5,13,19.5,26,39,52,58.5,65 Mbps
EVM 802.11b 32% max
802.11g -26 dB max
802.11a -26 dB max
802.11n (2.4 GHz) -29 dB max
802.11n (5 GHz -29 dB max
Bluetooth Coexistence TI Wilink6 proprietary WiFi-BT co-existent scheme.
Tab l e D. 3
Parameter Sub-parameters Specifications
Tab l e D.4
Parameter Specifications
Form Factor Embedded surface mount module, 11.4 x 9.4 mm
* This is a combo module containing both Wi-Fi 802.11a/b/g/n and Bluetooth
V2.1+EDR radio
Antenna Port U.FL jack (shared with Wi-Fi 802.11b/g/n radio)
Antenna Type PIFA antenna. Covers 2400-2484 MHz
@ <2.0:1 VSWR
Antenna Gain 3.73 dBi
Transmit Power 6.5 dBm typical
Frequency Range 2.400-2.4835 GHz
Channel 79
RX Sensitivity -90 dBm typical, -70 dBm max
Data Rates -90 dBm typical, -70 dBm max
802.11 Coexistence TI Wilink6 proprietary WiFi-BT co-existent scheme.
