Appendix D: Specifications
Cinterion PH8 GSM/GPRS/EDGE Radio
Psion EP10 Hand-Held Computer User Manual
D-8
Operating Temperature (board
temperature)
Normal operation: -30°C to +85°C
Restricted operation: -40°C to +95°C
Physical Dimensions: 33.9mm x 50mm x 3.1mm
Weight: approx. 9.5g
RoHS All hardware components fully compliant with EU RoHS Directive
HSPA features
3GPP Release 6, 7 DL 14.4Mbps, UL 5.7Mbps
UE CAT. [1-6], 11, 12 supported
Compressed mode (CM) supported according to 3GPP TS25.212
UMTS features
3GPP Release 4 PS data rate - 384 kbps DL / 384 kbps UL
CS data rate - 64 kbps DL / 64 kbps UL
GSM/GPRS/EGPRS features
Data Transfer GPRS:
• Multislot Class 12
• Full PBCCH support
• Mobile Station Class B
• Coding Scheme 1 - 4
EGPRS:
• Multislot Class 12
• EDGE E2 power class for 8 PSK
• Downlink coding schemes - CS 1-4, MCS 1-9
• Uplink coding schemes - CS 1-4, MCS 1-9
• SRB loopback and test mode B
• 8-bit, 11-bit RACH
• PBCCH support
• 1 phase/2 phase access procedures
• Link adaptation and IR
• NACC, extended UL TBF
• Mobile Station Class B
CSD:
• V.110, RLP, non-transparent
• 14.4kbps
• USSD
SMS Point-to-point MT and MO
Cell broadcast
GPS features
Protocol NMEA
Modes Standalone GPS, Assisted GPS (control plane AGPS, E911 / user plane AGPS,
gpsOneXTRA™)
General Power saving modes
GPS tracking in parallel to 2G/3G diversity operation
Software
AT Commands Hayes, 3GPP TS 27.007 and 27.005, and proprietary Cinterion Wireless
Modules commands
SIM Application Toolkit SAT Release 99
Audio Audio speech codecs
GSM: AMR, EFR, FR, HR
3GPP: AMR
Speakerphone operation, echo cancellation, noise suppression
Firmware Update Generic update from host application over ASC0 or USB
Interfaces
Module Interface 80-pin board-to-board connector
Tab l e D. 6
Feature Specifications
