I/O Interface
QL-30/60 User Guide 129
18 RSTERR Reset
Error state of the printer will
be reset.
Switch on +24 V
between Pin 18 and
Pin 25
19 P24_INT Internal operating voltage
+24 V, Si T 100mA for
external consumers e.g.
sensors, trigger switches
20 P24_EXT External operating voltage
+24 V
21 PEELPOS Label in peel-off position
For peel-off mode only.
A label is in peel-off position.
+24 V on Pin 21
Bit 3 User Bit 3 is set
22 ERROR General error message
The operation will be stopped
and the error type will be
displayed.
0 V on Pin 22
23 STOP Stop signal to interrupt the
operation
Switch on +24 V
between Pin 23 and
Pin 25
24 - - Do not use
25 GND_EXT Ground of the external 24 V
Table 45: Pin assignment of the I/O interface (Continued)
Pin Signal Name Description
Activation / Active
State
