Alteon Application Switch Operating System Application Guide

Server Load Balancing

178 Document ID: RDWR-ALOS-V2900_AG1302

Figure 30: Example Buddy Server Health Check Configuration

To add a real server as a buddy server for another real server

To remove a real server as a buddy server

>> Main# /cfg/slb/real <real server number> /adv/buddyhc/addbd <real server

number> <real server group> <service>

>> Main# /cfg/slb/real <real server number> /adv/buddyhc/delbd <real server

number> <real server group> <service>
