WAN Link Load Balancing
Document ID: RDWR-ALOS-V2900_AG1302 641
3. Configure the IP interfaces on Alteon. Alteon must have an IP route to all of the real servers that
receive switching services. For load balancing the traffic, Alteon uses this path to determine the
level of TCP/IP reach of the WAN links.
Step 2—Configure the Load Balancing Parameters for ISP Routers
Configure the ISP routers with load balancing parameters: real servers, group, metric, and health.
1. Configure IP addresses for WAN link routers.
Proxy is disabled on the real servers, so that the original destination IP address is preserved.
>> # /cfg/port 25/pvid
(Clear STG)
>> # /cfg/l2/stg 1/port 1257
(Add ports 1, 2, 5, and 7 to STG 1)
>> Main # /cfg/l3/if 2
(Define interface 2 for ISP 1)
>> IP Interface 2 # ena
(Enable interface 2)
>> IP Interface 2# addr 50.1.1.2
(Define the IP address for interface 2)
>> IP Interface 2# mask 255.255.255.0
(Define the mask for interface 2)
>> IP Interface 2# broad 50.1.1.255
(Define the broadcast for interface 2)
>> IP Interface 2 # vlan 2
(Specify the VLAN for interface 2)
>> Main # /cfg/l3/if 7
(Define interface 7 for ISP 2)
>> IP Interface 7# ena
(Enable interface 7)
>> IP Interface 7# addr 80.1.1.2
(Define the IP address for interface 7)
>> IP Interface 7# mask 255.255.255.0
(Define the mask for interface 7)
>> IP Interface 7# broad 80.1.1.255
(Define the broadcast for interface 7)
>> IP Interface 7# vlan 7
(Specify the VLAN for interface 7)
>> Main # /cfg/l3/if 1
(Define interface 1 for Real server 3)
>> IP Interface 1# ena
(Enable interface 1)
>> IP Interface 1# addr 1.1.1.1
(Define the IP address for interface 1)
>> IP Interface 1# mask 255.255.255.0
(Define the mask for interface 1)
>> IP Interface 1# broad 1.1.1.255
(Define the broadcast for interface 1)
>> IP Interface 1# vlan 1
(Specify the VLAN for interface 1)
>> Main # /cfg/l3/if 5
(Define interface 5 for internal client)
>> IP Interface 5# ena
(Enable interface 5)
>> IP Interface 5# addr 2.2.2.1
(Define the IP address for interface 5)
>> IP Interface 5# mask 255.255.255.0
(Define the mask for interface 5)
>> IP Interface 5# broad 2.2.2.255
(Define the broadcast for interface 5)
>> IP Interface 5# vlan 5
(Specify the VLAN for interface 5)
>> # /cfg/slb/real 1/rip 50.1.1.1
(Define IP address for WAN link 1)
>> Real server 1# ena
(Enable real server 1)
>> Real server 1# proxy dis
(Disable proxy)
>> # /cfg/slb/real 2/rip 80.1.1.1
(Define IP address for WAN link 2)
>> Real server 2# ena
(Enable real server 2)
