WAN Link Load Balancing
648 Document ID: RDWR-ALOS-V2900_AG1302
4. Configure the IP interfaces on Alteon.
Step 2—Configure the Load Balancing Parameters for ISP Routers
On Alteon, configure the ISP routers as if they were real servers, with SLB parameters: real servers,
group, metric, and health.
1. Configure IP addresses for WAN link routers.
Proxy is disabled on the real servers, because link load balancing and full NAT cache redirection
cannot coexist.
>> # /cfg/vlan 1/def 1
(Add port 1 to VLAN 1)
>> # /cfg/vlan 5/ena
(Enable VLAN 5)
>> # /cfg/vlan 5/def 5
(Add port 5 to VLAN 5)
>> # /cfg/stp 1/off
(Disable STP)
>> # /cfg/stp 1/clear
(Clear STP)
>> # /cfg/stp 1/add 1 25 26 5
(Add ports 1, 25, 26, 5 to STP 1)
>> # /cfg/if 1
(Define interface 1)
>> IP Interface 1# ena
(Enable interface 1)
>> IP Interface 1# addr 1.1.1.1
(Define the IP address for interface 1)
>> IP Interface 1# mask 255.255.255.0
(Define the mask for interface 1)
>> IP Interface 1# broad 1.1.1.255
(Define the broadcast for interface 1)
>> IP Interface 1# vlan 1
(Specify the VLAN for interface 1)
>> # /cfg/if 2
(Define interface 2)
>> IP Interface 2# ena
(Enable interface 2)
>> IP Interface 2# addr 50.1.1.2
(Define the IP address for interface 2)
>> IP Interface 2# mask 255.255.255.0
(Define the mask for interface 2)
>> IP Interface 2# broad 50.1.1.255
(Define the broadcast for interface 2)
>> IP Interface 2# vlan 2
(Specify the VLAN for interface 2)
>> # /cfg/if 7
(Define interface 7)
>> IP Interface 7# ena
(Enable interface 7)
>> IP Interface 7# addr 80.1.1.2
(Define the IP address for interface 7)
>> IP Interface 7# mask 255.255.255.0
(Define the mask for interface 7)
>> IP Interface 7# broad 80.1.1.255
(Define the broadcast for interface 7)
>> IP Interface 7# vlan 7
(Specify the VLAN for interface 7)
>> # /cfg/slb/real 1/rip 50.1.1.1
(Define IP address for WAN link 1)
>> Real server 1# ena
(Enable real server 1)
>> Real server 1# proxy dis
(Disable proxy)
>> # /cfg/slb/real 2/rip 80.1.1.1
(Define IP address for WAN link 2)
>> Real server 2# ena
(Enable real server 2)
>> Real server 2 # adv
(Select the advance menu)
>> Real server 2 Advanced# proxy dis
(Disable proxy)
