Radware Alteon User Manual

Alteon Application Switch Operating System Application Guide
Firewall Load Balancing
664 Document ID: RDWR-ALOS-V2900_AG1302
11. Add filters to the ingress port.
Note: When adding an IPv4 static route, if you are using FWLB and you define two IP
interfaces on the same subnet, where one IP interface has a subnet of the host which is also
included in the subnet of the second interface, you must specify the interface.
12. Define static routes to the clean-side IP interfaces, using the firewalls as gateways.
One static route is required for each firewall path being load-balanced. In this case, two paths
are required: one that leads to clean-side IF 2 (10.1.3.1) through the first firewall (10.1.1.10)
as its gateway, and one that leads to clean-side IF 3 (10.1.4.1) through the second firewall
(10.1.2.10) as its gateway.
13. Apply and save the configuration changes
To configure the clean-side Alteon
1. Define the clean-side IP interfaces. Create one clean-side IP interface on a different subnet for
each firewall being load balanced.
Note: An extra IP interface (IF 1) prevents server-to-server traffic from being redirected.
2. Configure the dirty-side IP interfaces as if they were real servers on the clean side.
>> SLB Port 5# /cfg/l3/route/ip4
>> IP Static Route# add 10.1.3.1 255.255.255.255 10.1.1.10
>> IP Static Route# add 10.1.4.1 255.255.255.255 10.1.2.10
>> # apply
>> # save
>> # /cfg/l3/if 1
(Select IP Interface 1)
>> IP Interface 1# addr 20.1.1.1
(Set IP address for Interface 1)
>> IP Interface 1# mask 255.255.255.0
(Set subnet mask for Interface 1)
>> IP Interface 1# ena
(Enable IP Interface 1)
>> IP Interface 1# /cfg/l3/if 2
(Select IP Interface 2)
>> IP Interface 2# addr 10.1.3.1
(Set the IP address for Interface 2)
>> IP Interface 2# mask 255.255.255.0
(Set subnet mask for Interface 2)
>> IP Interface 2# ena
(Enable IP Interface 2)
>> IP Interface 2# /cfg/l3/if 3
(Select IP Interface 3)
>> IP Interface 3# addr 10.1.4.1
(Set the IP address for Interface 3)
>> IP Interface 3# mask 255.255.255.0
(Set subnet mask for Interface 3)
>> IP Interface 3# ena
(Enable IP Interface 3)
