Alteon Application Switch Operating System Application Guide
Firewall Load Balancing
Document ID: RDWR-ALOS-V2900_AG1302 681
Note: The clean-side Alteon must use the same metric as defined on the dirty side. For
information on using metrics other than hash, see Free-Metric FWLB, page 683
.
2. Create an SLB real server group on the primary clean-side Alteon to which traffic will be load
balanced.
The external clients are configured to connect to HTTP services at a publicly advertised IP
address. The servers on this network are load balanced by a virtual server on the clean-side
Alteon. SLB options are configured as follows:
Note: The virtual server IP address configured in this step will also be configured as a Virtual
Server Router (VSR) when VRRP is configured in a later step.
>> # /cfg/slb
(Select the SLB menu)
>> # real 20
(Select Real Server 20)
>> # rip 10.10.4.20
(Set IP address of Real Server 20)
>> # ena
(Enable)
>> # /cfg/slb.real 21
(Select Real Server 21)
>> # rip 10.10.4.21
(Set IP address of Real Server 21)
>> # ena
(Enable)
>> # /cfg/slb/real 22
(Select Real Server 22)
>> # rip 10.10.4.22
(Set IP address of Real Server 22)
>> # ena
(Enable)
>> # /cfg/slb/group 2
(Select Real Server group 2)
>> # add 20
(Add the Real Servers to the group)
>> # add 21
>> # add 22
>> # metric leastconns
(Select least connections as the
load-balancing metric)
>> # /cfg/slb/virt 1
(Select the Virtual Server 1 menu)
>> # vip 10.10.4.100
(Set the virtual server IP address)
>> # service http
(Select HTTP for load balancing)
>> # group 2
(Add Real Server Group 2)
>> # ena
(Enable the virtual server)
>> # /cfg/slb/port/26/server ena
(Enable server processing on the
port connected to the real servers)
>> # /cfg/slb/port/25/client ena
(Enable client processing on the port
connected to the firewall)
>> # /cfg/slb/port/28/client ena
(Enable client processing on the
interswitch connection)
