Radware Alteon - Page 682

Alteon Application Switch Operating System Application Guide
Firewall Load Balancing
682 Document ID: RDWR-ALOS-V2900_AG1302
3. Create the FWLB filters on the primary clean-side Alteon.
Three filters are required on the port attaching to the real servers:
— Filter 10 prevents local traffic from being redirected.
— Filter 20 prevents VRRP traffic from being redirected.
— Filter 2048 redirects the remaining traffic to the firewall group.
4. Configure VRRP on the primary clean-side Alteon.
VRRP in this example requires two virtual routers to be configured: one for the subnet attached
to the real servers and one for the subnet attached to the firewalls.
>> # /cfg/slb/filt 10
>> # dip 10.10.4.0
>> # dmask 255.255.255.0
>> # ena
>> # /cfg/slb/filt 20
>> # dip 224.0.0.0
>> # dmask 255.255.255.0
>> # ena
>> # /cfg/slb/filt 2048
>> # action redir
>> # group 1
>> # ena
>> # /cfg/slb/port 4
>> # filt ena
>> # add 10
>> # add 20
>> # add 2048
>> # /cfg/l3/vrrp
>> # on
>> # vr 1
>> # vrid 3
>> # addr 10.10.4.9
>> # if 1
>> # prio 100
>> # share dis
>> # ena
>> # track
>> # ifs ena
>> # ports ena
>> # /cfg/l3/vrrp/vr 2
>> # vrid 4
>> # addr 10.10.3.9
>> # if 2
>> # prio 101
>> # share dis
>> # ena
>> # track
>> # ifs ena
>> # ports ena
