Alteon Application Switch Operating System Application Guide
Virtual Private Network Load Balancing
Document ID: RDWR-ALOS-V2900_AG1302 701
3. Turn off Spanning Tree Protocol (STP).
4. Configure IP interfaces 1, 2, and 3.
5. Configure routes for each of the IP interfaces you configured in step 4
.
6. Configure VRRP for Virtual Routers 1 and 2.
7. Enable SLB.
8. Configure real servers for health checking VPN devices.
9. Enable the real server group, and place real servers 1 through 4 into the real server group.
>> # /cfg/l2/stg/off
>> # /cfg/l3/if 1/ena/mask 255.255.255.0/addr 192.168.10.11
>> # /cfg/l3/if 2/ena/mask 255.255.255.0/addr 10.0.0.20/vl 2
>> # /cfg/l3/if 3/ena/mask 255.255.255.255/addr 10.0.0.21/vl 2
>> # /cfg/l3/route
>> # add 20.0.0.10 255.255.255.255 10.0.0.101 2
>> # add 20.0.0.11 255.255.255.255 10.0.0.102 3
>> # add 20.0.0.20 255.255.255.255 10.0.0.101 2
>> # add 20.0.0.21 255.255.255.255 10.0.0.102 3
>> # /cfg/l3/vrrp/on
>> # /cfg/l3/vrrp/vr 1
>> # ena
>> # vrid 1
>> # if 1
>> # addr 192.168.10.50
>> # share dis
>> # track
>> # vrs ena
>> # ports ena
>> # /cfg/l3/vrrp/vr 2
>> # ena
>> # vrid 2
>> # if 2
>> # addr 10.0.0.1
>> # share dis
>> # track
>> # vrs ena
>> # ports ena
>> # /cfg/slb/on
>> # /cfg/slb/real 1/ena/rip 20.0.0.10
>> # /cfg/slb/real 2/ena/rip 20.0.0.11
>> # /cfg/slb/real 3/ena/rip 20.0.0.20
>> # /cfg/slb/real 4/ena/rip 20.0.0.21
