Global Server Load Balancing

Document ID: RDWR-ALOS-V2900_AG1302 729

Figure 122: DNS Console

6. Set TTL equal to 10 seconds for records of zone “com”.

7. Disable the round-robin algorithm for the server as shown in Figure 123 - ZDEDIC-5 Properties

Window, page 729.

Figure 123: ZDEDIC-5 Properties Window

Note: If the DNS server is down, the clients (PCC, Sigma phone that supports DNS and AudioCodes

GW) do not work.
