Radware Alteon User Manual

Alteon Application Switch Operating System Application Guide
Bandwidth Management
Document ID: RDWR-ALOS-V2900_AG1302 779
4. Configure BWM contract 1. Each contract must have a unique number from 1 to 1024.
5. Assign the bandwidth policy 1 to Contract 1.
6. Enable Contract 1.
7. Select Bandwidth Policy 2.
8. Set the hard, soft, and reserved rate limits for this policy, in Mbps.
9. On Alteon, select BWM Contract 2.
10. Assign Bandwidth Policy 2 to Contract 2. Each BWM contract must be assigned a bandwidth
policy.
11. Enable Contract 2.
12. As described in step 7 through step 11, configure Policy 3 with hard, soft, and reserved limits of
30, 25, and 20 Mbps respectively. Then create Contract 3 and apply Policy 3 to this contract.
13. Configure Policy 4 with hard, soft, and reserved limits of 40, 35, and 30 Mbps respectively. Then
create Contract 4 and apply Policy 4 to this contract.
14. Configure BWM Contract Group 1 and add all four contracts to this group.
>> # /cfg/bwm/pol 1
>> Policy 1# hard 10M
>> Policy 1# soft 5M
>> Policy 1# resv 1M
(Select BWM Policy 1)
(Set "never exceed" rate)
(Set desired bandwidth rate)
(Set committed information rate)
>> Policy 1# /cfg/bwm/cont 1
>> BWM Contract 1# pol 1
>> BWM Contract 1# ena
>> BWM Contract 1# /cfg/bwm/pol 2
>> Policy 2# hard 20
>> Policy 2# soft 15
>> Policy 2# resv 10
(Set "never exceed" rate)
(Set desired bandwidth rate)
(Set committed information rate)
>> Policy 2# /cfg/bwm/cont 2
>> BWM Contract 2# pol 2
>> BWM Contract 2# ena
>> /cfg/bwm/group 1
>> BW Group 1# add 1
Contract 1 added to group 1.
(Select Contract Group 1)
(Add Contract 1 to Group 1)
>> BW Group 1# add 2
Contract 2 added to group 1.
>> BW Group 1# add 3
(Add Contract 2 to Group 1)
(Add Contract 3 to Group 1)
