Alteon Application Switch Operating System Application Guide
Content-Intelligent Server Load Balancing Not Using Layer 7 Content
Document ID: RDWR-ALOS-V2900_AG1302 823
4. Configure Filter 3.
5. Apply and save the configuration.
Example TCP Service Port Based HTTP Redirection
In this example, Alteon redirects traffic entering Alteon on one TCP service port, and redirects it
through another service port. Use the provided string index numbers to configure a redirection map
for each filter.
• Filter 4—Configure a filter to examine the URL request http://10.46.6.231:80/
Connect1.jad on TCP service port 80, and redirect that URL to TCP service port 90.
• Filter 5—Configure a filter that intercepts all traffic entering on TCP service port 80, and send it
to 10.168.120.129 on TCP service port 8080.
>> /cfg/slb/filt 3
>> Filter 3 # sip 10.23.43.0
Current source address: any
New pending source address: 10.23.43.0
>> Filter 3 # smask 255.255.255.0
Current source mask: 0.0.0.0
New pending source mask: 255.255.255.0
>> Filter 3 # proto tcp
Enter protocol or any: udp
Pending new protocol: tcp
>> Filter 3 # dport http
Current destination port or range: any
Pending new destination port or range: http
>> Filter 3 # action redir
Current action: allow
Pending new action: redir
>> Filter 3 # /cfg/slb/filt/adv/layer7
>> Layer 7 Advanced# addrd
Enter filtering string ID (1-1024) to redirect from: 5
Enter filtering string ID (2-1024) to redirect to: 6
