WinLink™ 1000 User Manual Release 1.9 A-1
Appendix A
Pole and Wall Installation
ODU Mounting Kit Contents
Table A-1: Bill of Materials: ODU mounting kit
Item Qty
Large Clamp (see Figure A-1)
1
Small Clamp (see Figure A-2)
1
Arm (see Figure A-3)
1
Screw hex head M8x40
4
Screw hex head M8x70
2
Washer flat M8
4
Washer spring M8
3
M8 Nuts
2
Figure A-1: Large Clamp Figure A-2: Small Clamp Figure A-3: Arm
