WinLink™ 1000 User Manual Release 1.9 S-1
Appendix S
RF Exposure
The antennas used for the following transmitters must be installed so as to
provide a minimum separation distance from by-standers as specified in the
following tables.
WinLink™ 1000 Safety Distances
Table S-1: Safety Distances for WinLink™ 1000 FCC and IC Products
Frequency
Band [GHz]
FCC ID IC ID
Antenna
gain [dBi]
Min. Safety
Distance [cm]
5.8 Q3KAMWL1000 5100A-AMWL1000 22 42
5.8 Q3KAMWL1000 5100A-AMWL1000 28 83
5.8 Q3KAMWL1580 22 109
5.8 Q3KAMWL1580 28 217
5.8 Q3KAMWL1580 32.5 364
2.4 Q3KAMWL1240 5100A-AMWL1240 16 14
2.4 Q3KAMWL1240 5100A-AMWL1240 24 36
2.4 Q3KAMWL1240H 24 71
2.4 Q3KAMWL1240H 15.2 37
2.5 Q3KAMWL1250 17.5/24 200
4.9 Q3KAMWL1490H 5100A-AMWL1490H 27 98
4.9 Q3KAMWL1490H 5100A-AMWL1490H 18.5 42
5.3/5.4 Q3KAMWL1540C 5100A-AMWL1540C 22 20
Table S-2: Safety Distances for WinLink™ 1000
ETSI Products
Frequency
Band [GHz]
Antenna
gain [dBi]
Min. Safety
Distance [cm]
5.8 22 13
5.4 22 7
