Radwin WinLink 1000 Series User Manual

Antenna Characteristics Appendix N
WinLink™ 1000 User Manual Release 1.9 N-5
Antenna Characteristics
An antenna is the radiating and receiving element from which the radio sig-
nal, in the form of RF power, is radiated to its surroundings and vice versa.
The transmission range is a function of the antenna gain and transmitting
power. These factors are limited by country regulations.
The WinLink™ 1000 may be operated with an integrated antenna attached
to the ODU unit, or with an external antenna wired to the ODU via an N-
type connector. All cables and connections must be connected correctly to
reduce losses. The required antenna impedance is 50Ω.
Frequency
range
Frequency bands
Form
factor
Type Gain
Beam
width
Dimen-
sions
2.4
GHz
2.5
GHz
4.9
GHz
5.3
GHz
5.4
GHz
5.8
GHz
5.9
GHz
2.40-2.70 GHz √ Integrated Flat panel 16dBi 20° 1ft
2.30-2.70 GHz √ √ Integrated Flat panel 17.5dBi 25° 1ft
2.400-2.483 GHz √ External
Grid 24dBi
E:14°
H:10°
2ft / 3ft
Omni 6dBi
E:25°
H:360°
1.2ft
2.50-2.70 GHz √ External Grid 24dBi
E:13°
H:9°
2ft / 3ft
4.90-5.10 GHz √ External Flat panel 27dBi 5° 2ft
4.90-5.00 GHz √ External Dish 27dBi 8° 2ft
4.94-6.00 GHz
√
Integrated Flat panel
18.5dBi
10° 1ft
√ √ √ √ 22dBi
4.90-5.35 GHz √ External Flat panel 21dBi 9° 1ft
5.150-5.350 GHz √ External Dish 31dBi 5° 3ft
5.470-5725 GHz √ External Dish 31.5dBi 4° 3ft
5.15-6.00 GHz √ √ √ √ External Flat panel
22dBi 9° 1ft
28dBi 4.5° 2ft
5.15-5.85 GHz √ External Flat panel 9.5dBi
E:32°
H:73°
0.4ft /
0.3ft
5.725-5.850 GHz √ External Dish
32.5dBi
6°
3ft
29dBi 2ft
5.150-5.875 GHz √ √ √ External Flat panel 18dBi 18° 0.6ft
