WinLink™ 1000 User Manual Release 1.9 M-1
Appendix M
Video Surveillance
About the RADWIN Video Surveillance Product
RADWIN’s Video Surveillance solution provides an inexpensive asymmetric
link: A fast uplink for a real time video stream from a camera site to the sur-
veillance base and a slower command downlink from the base to the cam-
era site.
The Video Surveillance (VS) product belongs to RADWIN’s Access line. A VS
link consists of a base ODU transmitting at 2Mbps connected by a PoE
device. The camera site uses a PoE connected ODU transmitting at 5Mbps.
Installation, configuration and maintenance of a VS link is substantially the
same as for a regular PoE based link. VS links are readily collocated using
RADWIN’s HSS system, so that a single base mast can accommodate up to
16 camera stations.
Figure M-1: Collocated basic VS configuration
Note
Consider replacing control center PoE devices with one or more RADWIN
BDUs.
