LAN Port for PoE-8 Appendix O
WinLink™ 1000 User Manual Release 1.9 O-2
LAN Port for PoE-8
When connecting the PoE-8 LAN port cable directly to PC, a crossed
LAN cable, terminated with RJ-45 connectors on both ends must be
used, wired according to Table O-3:
O-PoE to PC LAN Cable
When connecting the O-PoE ETH port cable directly to a PC, a
crossed LAN CAT-5e, 4 twisted-pair 24 AWG STP, terminated with
RJ-45 connectors on both ends must be used. The pinout in
Table O-3 applies here.
Trunk Ports - E1/T1 RJ45 Connector
The E1/T1 interfaces terminate in 8-pin RJ-45 connectors, as shown in
Table O-4 below:
Hot Standby Port RJ-11
Receive Data (positive) RD (+) 3
Receive Data (negative) RD (–) 6
Table O-3: Fast Ethernet Connector Pinout
Function Color PC
Ethernet (RxN) White/Green 3
Ethernet (RxT) Green 6
Ethernet (TxT) White/Orange 1
Ethernet (TxN) Orange 2
Table O-4: Trunk Ports - E1/T1 RJ45Pinout
Function Signal Pin
Transmit Data Tip TxTip 1
Transmit Data Ring TxRing 2
Receive Data Tip RxTip 4
Receive Data Ring RxRing 5
Table O-5: Hot Standby RJ-11 Port Pinout
Signal Pin
HSB out 1
HSB in 2
Table O-2: Fast Ethernet Connector Pinout (Continued)
Function Signal Pin
