The Outdoor Unit (ODU) Chapter 1
WinLink™ 1000 User Manual Release 1.9 1-8
This ODU has one N-type connector for connecting an external
antenna.
There are four series of WinLink™ 1000 ODU’s:
• WinLink™ 1000 Access
• WinLink™ 1000 VS
• WinLink™ 1000
• WinLink™ 1000 High End
The following table shows the differences between the four systems:
The WinLink™ 1000 ODUs come is many variations reflecting supported
combinations of regulations and frequency bands as shown in Table 1-2
:
Key to abbreviations:
• FCC - Federal Communications Commission
• IC - Canadian radio regulation
Table 1-1: ODU Series Typical Characteristics
WinLink™ 1000
Access
WinLink™ 1000
VS
WinLink™ 1000
WinLink™ 1000
High End
Max Ethernet
Throughput
2Mbps 2/5 Mbps 18Mbps 18Mbps
Max. Range 20Km 20Km 80Km 80Km
Supported IDU
devices
PoE PoE PoE and IDU PoE and IDU
Services Ethernet Ethernet Ethernet and TDM
Ethernet and
TDM
HSS Yes Yes No Yes
Tx Power 18 dBm 18dBm 18 dBm 25 dBm
Table 1-2: WinLink™ 1000 Frequency Bands And Radio Regulations
FCC/IC ETSI
IDA
(WPC India)
CN
(MII China)
UK
HP
(Universal)
2.3 GHz 2.302 - 2.397
2.4 GHz 2.402 - 2.472 2.402 - 2.482 2.312 - 2.482
2.5 GHz 2.496 - 2.690 2.496 - 2.690
2.7 GHz 2.700 - 2.900
4.9 GHz 4.940 - 4.990 4.940 - 4.990
5.3 GHz 5.250 - 5.350 5.170 - 5.330 5.140 - 5.345
5.4 GHz 5.475 - 5.720 5.490 - 5.710 5.475 - 5.720
5.8 GHz 5.730 - 5.845 5.725 - 5.875 5.825 - 5.875 5.730 - 5.845 5.725 - 5.845
5.9 GHz 5.730 - 5.950
6.0 GHz 5.795 - 6.030
