DC Power Terminals Appendix O
WinLink™ 1000 User Manual Release 1.9 O-4
Figure O-1: Example for connecting the alarm connector
DC Power Terminals
IDU-C and BDU
IDU-E
Table O-7: Terminal Block 3-pin -48VDC
Function Pin
+ Right
Chassis Center
– Left
Table O-8: Terminal Block 2-pin -48VDC
Function Pin
+ Right
– Left
