Example: //Query measurement bandwidth
BWID:MEAS?
Usage: Query only
Manual operation: See "Allan Variance / Allan Deviation" on page 92
TRACe<n>[:DATA]? <Trace>
This command queries the trace data (measurement results).
Suffix:
<n>
.
1..n
Window
Query parameters:
<Trace> TRACE1 | ... | TRACE6
Queries the data of one of the colored line traces.
XGINdicator
Queries the data of the cross-correlation gain indicator (grey
area).
Return values:
<Result> • Phase noise measurements
Coordinates of the trace as list of comma-separated values,
beginning at the nearest offset frequency.
Example: //Query trace data
TRAC? TRACE1
would return the data of trace 1, e.g.:
1000.000000,-82.326393,1011.579712,-82.411499,
1023.292969,-82.538643,[...]
Usage: Query only
Manual operation: See "Noise Diagram" on page 88
See "Allan Variance / Allan Deviation" on page 92
See "Frequency (VCO Characterization)" on page 93
See "Sensitivity" on page 93
See "Power" on page 93
See "Current / Voltage" on page 94
See "Power vs. Frequency" on page 94
See "Harmonic Power" on page 94
See "Spot Noise vs Tune PN" on page 95
See "Spot Noise vs Tune AM" on page 95
See "Frequency (Transient Analysis)" on page 95
See "Frequency Deviation" on page 96
See "Phase" on page 96
TRACe<n>[:DATA]:LINear? <Trace>, <Points>[, <Start>, <Stop>]
This command queries the trace data with linear interpolation.
